Why would I use a blower, and what type of blower do I need?
High Pressure Blowers
The high-pressure blower or blower fan is used to create a positive pressure for applications such as: inflatable structures, manufacturing processes, production assembly lines, equipment or product cooling, electronic cooling and laboratories to name a few. Pressurization blowers are a type of fan that can create a positive pressure in a sealed or closed environment. These blowers are not restricted to the task of creating a positive pressure, but can also be used where ever a clean stream of air is needed: conveyor belts, welding areas, wood working shops, assembly lines. The explosion proof version of the pressure blower is designed to work within hazardous environments where there may be corrosive or flammable such as those found in a petrochemical plant, paint booths, mills, tanks, and chemical processing operations.
How do I select the right pressure blower fan for my needs?
Selecting the right pressure blower is based on the performance specifications and materials of construction of the fan. Knowing the air flow rate is very important. This is the rate at which the air moves either within or between two or more zones. The static pressure rating is also important. this thing called static pressure is the pressure that exists when an equal amount of air is supplied to, and exhausted from a space. The static pressure will rise when more air is supplied then is exhausted from a given area. The diameter of the blower fan inlet and outlet is also an important piece to consider when selecting a unit. Other factors to consider when making your choice are horsepower, voltage, phase, and whether to choose a direct drive or belt drive unit. The build material that make up a pressure blower can include aluminum, cast iron, steel, stainless steel, plastics, and composite materials.
Low Pressure Volume Blowers
Unlike the high pressure blower, the high volume or high airflow blower fan does not pressurize or sustain a given pressure within a closed or sealed environment. These blowers are designed to pull in or push out large volumes of air which are rated in CFM's or cubic feet per minute. Volume blowers are designed to function within a low static pressure environment, and will not perform well in medium to high static locations. Applications for these blower fans include forced cooling of AC and DC motors, electrical cabinet ventilation, plastics process cooling, ink drying in printing rooms, general combustion air, removal of welding smoke and fumes.
Standard and explosion proof blowers and blower cooling fans come in a wide range of types: Pressure Blowers for areas or ducting with moderate to high static pressures, Volume Blowers to move a large amount of air over a specific area, Radial Blade Blowers for high static pressures, greenhouse inflation or exhaust, Utility Blowers for for moving air in low static pressure areas. Whatever the requirement, Industrial Fans Direct has the blower fan for your assembly line, warehouse, duct system, greenhouse, factory, spray booth and more.
What would I use a Regenerative Blower For?
There are many application for Regenerative Blowers. In many cases these types of blowers can be used to replace compressors, and be much less costly to use. These Regenerative Blowers come in single stage and two stage versions. Single stage units utilize a single impeller to accomplish the air movement, whereas the two stage blowers have two impellers for moving air in an higher pressure environment. Some of the applications include:
Air knife systems
Industrial drying/blow-off application. (parts, bottles, containers,…etc.)
Waste water aeration
Vacuum hold down
Vacuum cleaning systems
Vacuum cleaning systems
Gasoline vapor recovery
Lagoon gas recovery
Landfill gas evacuation and collection
Weld fume extraction
Dental equipment operation
Pneumatic air tube conveying systems
Inflation Blowers and their uses
Energy efficient PSC Inflation Blowers fare designed to inflate double poly greenhouses for greater insulation capabilities. All models have adjustable damper doors to regulate air flow as the poly expands. Industrial Fans Direct offers Inflation Blowers with a heavy gauge steel housing and forward curve metal wheel that is balanced for smooth operation. Oversized mounting holes on the discharge flange fit most industry standard brackets.
