Specs for Modine Hot Dawg Separated Combustion Natural Gas Aluminized Steel Garage Unit Heater 45000 BTU 115V 1 Phase HDS45AS0111
Item #: HDS45AS0111FBAN
46° F
45,000
Aluminized Steel
USA
841459
27'
60
Yes
10'
1 Phase
40 lbs
120
10 Year Limited
Virginia, USA
Modine Hot Dawg Separated Combustion Natural Gas Aluminized Steel Garage Unit Heater 45000 BTU 115V 1 Phase HDS45AS0111
The Hot Dawg separated combustion garage heater pulls 100% of the combustion air from outside, making this unit ideal for workspaces such as wood shops or a garage where paint or flammable materials are used regularly. The fresh air supply reduces the common concerns about performance and durability that can come when working in a dusty or particulate laden environment.
Certified for residential, commercial, and industrial use.
MOUNTING HEIGHT (MAX) 10 ft.
HEAT THROW 27 ft.
FEATURES Made in the USA Draws fresh air from outside, ensuring dust, dirt or fumes do not affect durability or performance Factory assembled, certified separated combustion. No add-ons needed allow for an easier and quicker installation providing greater durability and reduced maintenance. Quiet operation allows your space to be warm without the distraction of a loud machine running in the background Unit can easily be rotated to allow for convenient right or left side control placement NOTE: For model sizes 30-75 Fuel type: Natural or propane gas Low-profile, lightweight design easily installs 1" from ceiling with only two angle brackets NOTE: Included on sizes 30-75, accessory for sizes 100, 125 Casing construction made of heavy gauge metal Full 10-year warranty on heat exchanger Permanently lubricated motor for maintenance-free dependability Single- or two-stage controls available Direct spark ignition for reliable and consistent ignition 100% shut-off with continuous retry to allow for safe ignition in the event the unit doesn't light on the first try Factory installed finger proof fan guards
